SPCO Device with metalized gate pad at the top right and air gap trench on the edge of drain, lower left.

Alkaline Zincate Pretreatment

This process uses a double zincate chemistry that deposit zinc on the aluminum pads and then removes it and re-deposits a second thinner layer of zinc. This technique reduces the amount of zinc on the surface the second time which enhances adhesion by reducing the zinc trapped at the interface. Zinc that is trapped at the interface produces a brittle interface and reduced adhesion

Another important reason for using alkaline zincate is the ability to process pure aluminum. Pure aluminum has less electrical resistance and is used commonly in higher performance devices. Alkaline zincate is capable of oxidizing the pure aluminum surface and depositing zinc whereas the Acid zincate is far less aggressive to the passive aluminum surface and deposits zinc at a slower rate.

Benefits

 Improved Adhesion on pure Aluminum

 Increased removal of Aluminum on Pad

 Simple Operations and Controls

Phone: 562-437-0541

Fax: 562-437-8632

E-mail: info@stapletontech.com

To contact us:

Sequence 1020

Process Materials

Process Materials

Process

Description

Technical Data Sheet

Material Safety Data Sheet

MICRO 209

Cleaner, TMAH

MICRO 209 DS

MICRO 209 MSDS

MICRO 210

Cleaner, Organic Acid

MICRO 210 DS

MICRO 210 MSDS

MICRO 212

Cleaner, Organic Acid + HF

MICRO 212 DS

MICRO 212 MSDS

MICRO 242

Deox, Nitric Acid

MICRO 242 DS

MICRO 242 MSDS

MICRO 261

Alkaline Zincate

MICRO 261 DS

MICRO 261 MSDS

MICRO 282

Autocatalytic Nickel

MICRO 282 DS

MICRO 282 MSDS

MICRO 290

Immersion Gold

MICRO 290 DS

MICRO 290 MSDS

MICRO 291

Hybrid Autocatalytic Gold

MICRO 291 DS

MICRO 291 MSDS
